MXnet
Networked Video Ecosystem
MXNet is the AV over IP video distribution ecosystem from AVPro Edge. With the MXNet Ecosystem, integrators finally have an end-to-end solution developed with them in mind. Our engineering team focused on three things, stability of the entire system, interoperability with any HDMI source, display, USB device, or control system, and easy deployment of the entire system. MXNet allows for unlimited sources, displays, USB devices & video walls; MXNet is the perfect video distribution system for your next installation.
The Ecosystem
Below you can find each component of the ecosystem. Putting an ecosystem together is simple, with these determining questions you will know exactly what your installation calls for:
How many Sources? (this determines how many Encoder units you will need)
How many Displays? (this determines how many Decoder units you will need)
What type of signals are you using? 4K or 1080p (this determines how much data is needed)
ENCODERS/DECODERS
AC-MXNET-1G-E
MXNet 1G Encoder/Transmitter Device
1G Maximum Data Rate
Bandwidth management via MXNet Mentor
SFP Fiber Connection for Long Runs
Built-In “Data Window” OLED display
USB/KVM Host support
Full Exterior Light Control
RS-232 and IR Direct Routing
RS-232 over IP serial passthrough support
AC-MXNET-1G-AVDM-E
MXNet 1G Downmixing Encoder/Transmitter Device
1G Maximum Data Rate
Object and Lossless Stereo Downmixing
Bandwidth management via MXNet Mentor
SPF Fiber Connection for Long Runs
Built-In “Data Window” OLED display
USB/KVM Host support
Full Exterior Light Control
RS-232 and IR Direct Routing
RS-232 over IP serial passthrough support
AC-MXNET-1G-DANTE-E
MXNet 1G Encoder/Transmitter Device
1G Maximum Data Rate
Object and Lossless Stereo Downmixing
Bandwidth management via MXNet Mentor
SPF Fiber Connection for Long Runs
Built-In “Data Window” OLED display
USB/KVM Host support
Full Exterior Light Control
RS-232 and IR Direct Routing
RS-232 over IP serial passthrough support
Dante Encoder
SFP Fiber Connection for Long Runs
Bandwidth Management via MXNet Mentor
AC-MXNET-1G-EWP
MXNet 1G Encoder/Transmitter Device
Bandwidth management via MXNet MENTOR
Uses any standard category cable (CAT 5e or better)
Wall Plate Format that fits in standard Dual Gang mud rings
USB/KVM Host support
Full Exterior Light Control (for discreet Installs)
AC-MXNET-1G-D
MXNet 1G Decoder/Receiving Device
1G Maximum Data Rate
SFP Fiber Connection for Long Runs
Built-In “Data Window” OLED display
USB/KVM device support
Full Exterior Light Control
RS-232 and IR Direct Routing end point
Encapsulated RS-232 over IP serial passthrough
AC-MXNET-1G-EV2
Evolution II Encoding/Transmitting device
HDMI 2.0
18Gbps Bandwidth Support
HDCP 2.2 (and all earlier versions supported)
Evolution II ASIC with improved encoding engine
With “lossy” signals, JPEG 2000 optimizes compression efficiency
Proprietary MXNet Mentor interface for bandwidth management, real-time
status feedback, live diagnostics plus EDID copy and configuration
Encodes native 4K/60fps 4:4:4 RGB or YCbCr with dynamic metadata support
High Bitrate multi-channel support for Dolby Atmos and DTS:X
Downstream decoders now support ARC and eArc
Genlock frame-syncing ensures video walls are free from image-tearing
Near-zero latency, visually imperceptible
Configure control signal routing for RS-232, IR or USB via MXNet Mentor
USB/KVM support with USB 2.0 Type-B female Host connection
Improved USB 2.0 video processing for resolutions up to 1920x1080p @ 30Hz
Built-in OLED data window provides localized device information at a glance
Backed by AVPro Edge’s 10-year, no-hassle warranty
AC-MXNET-1G-AVDM-EV2
Evolution II Encoding/Transmitting device
HDMI 2.0
18Gbps Bandwidth Support
HDCP 2.2 (and all earlier versions supported)
Evolution II ASIC with improved encoding engine
With “lossy” signals, JPEG 2000 optimizes compression efficiency
Proprietary MXNet Mentor interface for bandwidth management, real-time
status feedback, live diagnostics plus EDID copy and configuration
Encodes native 4K/60fps 4:4:4 RGB or YCbCr with dynamic metadata support
High Bitrate multi-channel support for Dolby Atmos and DTS:X
Downstream decoders now support ARC and eArc
Genlock frame-syncing ensures video walls are free from image-tearing
Near-zero latency, visually imperceptible
Configure control signal routing for RS-232, IR or USB via MXNet Mentor
USB/KVM support with USB 2.0 Type-B female Host connection
Improved USB 2.0 video processing for resolutions up to 1920x1080p @ 30Hz
Built-in OLED data window provides localized device information at a glance• Backed by AVPro Edge’s 10-year, no-hassle warranty
8CH Audio Downmixing to 2CH
HDCP 2.3
4K/60fps 4:4:4
HDR, HDR 10 & Dolby Vision Support
Optimized Compression for Enhanced Imaging
AC-MXNET-1G-DANTE-EV2
Evolution II Encoding/Transmitting device
HDMI 2.0
18Gbps Bandwidth Support
HDCP 2.2 (and all earlier versions supported)
Evolution II ASIC with improved encoding engine
With “lossy” signals, JPEG 2000 optimizes compression efficiency
Proprietary MXNet Mentor interface for bandwidth management, real-time
status feedback, live diagnostics plus EDID copy and configuration
Encodes native 4K/60fps 4:4:4 RGB or YCbCr with dynamic metadata support
High Bitrate multi-channel support for Dolby Atmos and DTS:X
Downstream decoders now support ARC and eArc
Genlock frame-syncing ensures video walls are free from image-tearing
Near-zero latency, visually imperceptible
Configure control signal routing for RS-232, IR or USB via MXNet Mentor
USB/KVM support with USB 2.0 Type-B female Host connection
Improved USB 2.0 video processing for resolutions up to 1920x1080p @ 30Hz
Built-in OLED data window provides localized device information at a glance• Backed by AVPro Edge’s 10-year, no-hassle warranty
Dante audio Pass-through/Break-out Bridge
High bitrate 3D Immersive Audio Compatible
Optimized Video Compression for Artifact-free Images
Support for HDR10, HDR10+ and Dolby Vision
USB and KVM Support
AC-MXNET-1G-EV2WP
Evolution II Encoding/Transmitting device
HDMI 2.0
18Gbps Bandwidth Support
HDCP 2.2 (and all earlier versions supported)
Evolution II ASIC with improved encoding engine
With “lossy” signals, JPEG 2000 optimizes compression efficiency
Proprietary MXNet Mentor interface for bandwidth management, real-time
status feedback, live diagnostics plus EDID copy and configuration
Encodes native 4K/60fps 4:4:4 RGB or YCbCr with dynamic metadata support
High Bitrate multi-channel support for Dolby Atmos and DTS:X
Downstream decoders now support ARC and eArc
Genlock frame-syncing ensures video walls are free from image-tearing
Near-zero latency, visually imperceptible
Configure control signal routing for RS-232, IR or USB via MXNet Mentor
USB/KVM support with USB 2.0 Type-B female Host connection
Improved USB 2.0 video processing for resolutions up to 1920x1080p @ 30Hz
Low Latency, Native 4K/60 fps Support
Fits Standard NEMA Double-gang Wall Boxes
HDMI/USB-C Dual-inputs with Analog Audio Follow
Transformer-free, PoE Powered
Inputs Locally Selectable
Minimal Heat and Low Power Consumption
AC-MXNET-1G-DV2
Evolution II Decoder/Receiving Device
New Evolution II IC design greatly advances EV2 and DV2 encoding and decoding engine performance
4K/60fps, 4:4:4 support including Dolby Vision and HDR10+
Supports high bitrate, multi-channel audio codecs including
Dolby Atmos and IMAX Enhanced DTS:X
High-speed USB 2.0 for Webcam and KVM bi-directional support
AC-MXNET-1G-DANTE-DV2
Evolution II Decoder/Receiving Device
New Evolution II IC design greatly advances EV2 and DV2 encoding and decoding engine performance
4K/60fps, 4:4:4 support including Dolby Vision and HDR10+
Supports high bitrate, multi-channel audio codecs including
Dolby Atmos and IMAX Enhanced DTS:X
High-speed USB 2.0 for Webcam and KVM bi-directional support
Dante audio Pass-through/Break-out Bridge
High bitrate 3D Immersive Audio Compatible
Optimized Video Compression for Artifact-free Images
Support for HDR10, HDR10+ and Dolby Vision
USB and KVM Support
CONTROL
AC-MXNET-CBOX-HA
MXNet Control Box
The CBOX is the key to MXnet Ecosystem universe as the multicast routing, A/V data management, and control member of the team. The CBOX houses the system API used by MXnet Mentor and 3rd party control systems. The CBOX is POE powered and silently goes about its business of managing all things multicast and other data formats. The CBOX controls the whole Ecosystem, including audio/video switching/distributing, RS-232/USB/IR signal routing, video wall building, KVM and system management
MXNet MENTOR
MXNet setup and control software
Features:
• SYSTEM UTILITIES: Reboot and perform factory resets to CBOX, Encoders, and Decoders
• SETUP AND DIAGNOSTICS: Assign custom names to Encoders and Decoders
• AUTO-MATRIX: Easy to use and understand source to target the switching interface
• VIDEO WALLS: Unlimited with mosaic and asymmetrical arrays
• CEC AND RS-232 Passthrough
• RS-232 AND IR Direct Routing
NETWORK SWITCHES
AC-MXNET-SW12
MXnet 1G 12 Port Network Switch
Slotting into the MXnet ecosystem as a fast switching, low latency 12-port network switch for basic systems, the AVPro Edge AC-MXNET-SW12 is also perfect as a stackable add-on unit to our 24-port and 48-port switches, providing a flexible, lower cost extension option for planned or emergency system expansion. Four 10 Gbps SFP+ ports facilitate link aggregation through MXNet’s Mentor software.
AC-MXNET-SW24
MXNet 24 Port Network Switch
Full 24 port copper POE+ ports with 370 Watts of power available
Four 1GB SFP fiber port for longer runs
Four 10GB SFP fiber ports for stacking
Less than 2 seconds switching time
Less than 40ms latency
“Whisper” Quiet Operation
AVPro Edge engineered and optimized Multicast A/V firmware modules
IAVP – Intelligent A/V Processing
AC-MXNET-SW48
MXNet 48 Port Network Switch
Full 48 port POE+ 740 Watts
Four 10GB SFP fiber ports for stacking
Less than 2 seconds switching time
Less than 40ms latency
“Whisper” Quiet Operation
AVPro Edge engineered and optimized Multicast A/V firmware modules
IAVP – Intelligent A/V Processing
Network Switch Selection Guide
This guide will help you determine the model of network switch as well as the amount you will need for your next installation. We based the below chart on the number of “end points” you will be using, an “end point” is any place the audio/video signal starts or ends. The AC-MXNET-CBOX-HA is the controller device and you will need to dedicate one end point for control. Once you know how many sources and displays are in a system you can pick the correct switch layout.
Every system needs a Controller for signal switching, so make sure you dedicate one endpoint for the AC-MXNET-CBOX-HA.
