AVProEdge Matrix Switchers

AVPro Edge has a wide range of HDMI & HDBaseT Matrix Switchers. It’s a given, A/V integrator need to use a switch of some kind to manage a verity of sources and displays. AVPro Edge specialises in 18Gbps signals with HDR, and our matrices are no different. Switching time increases on “scaling” matrices due to the additional processing time for Sources/Displays and the matrix itself. If using a blended system (1080p/4K) you will likely want to select a switch with scalers. If doing an all 4K system, select one without for faster switching.

16x16 Matrix Switchers

AC-MX1616-AUHD-HDBT

​The AC-MX1616-AUHD-HDBT is a 16 input/output Matrix switch built to handle all the latest sources outputting 4K 60 (4:4:4) HDR video signals. What truly makes this switch the choice of integrators around the world is the ability to distribute 18Gbps 4K to some some zones and 1080p to others. We are able to accomplish this with our built in 4K to 1080p down scalers. This feature is one of many designed to help integrators throughout the installation process. Supporting the full HDMI 2.0 a/b specification and supporting every flavor of HDR, this matrix will ensure you can get the most out of any system. This 16×16 matrix switcher supports formats including HDR, HDR10, HDR10+, Dolby Vision, HLG, BBC and NHK. All of them are supported in up to 4K 60Hz and up to 12 Bit Deep Color. All color space compression is compatible. This powerhouse matrix switcher is the ideal solution for a multi zone setup that has 4K sources and up to 16 zones. Control’s a breeze as this switch comes with a web GUI you can access via the IP address, as well as drivers for all the top control systems. Combine that with the LED setup screen on the front, and you won’t have any problems getting this switch up and running. The AC-MX1616-AUHD-HDBT is the integrators choice for large multi zone distribution systems.

AC-MX1616-AUHD-HDBT-AVDM

The AC-MX1616-AUHD-HDBT-AVDM is a true high bandwidth powerhouse audio/video matrix switcher. What really makes this product special is the ability to downmix bitstream audio beyond 7.1 channel into a 2 channel audio signal via all 16 inputs. In a multi zoned distribution system every zone is not set to handle full dolby Atmos sound. Most zones are going to need 2 channel audio. This AC-MX1616-AUHD-HDBT-AVDM Matrix Switcher allows you to deliver 24+ channels to your Dolby Atmos home theater, at the same time it delivers 2 channel to the rest of the zones. We do this by allowing the downmixing to only affect the de-embedded audio output ports, the HDBaseT and HDMI ports leave the audio unimpeded, allowing you to distribute full dolby Atmos and DTS HD through them. Supporting the full HDMI 2.0 a/b specification and supporting every flavor of HDR, this matrix will ensure you can get the most out of any system. This 16×16 downmixing matrix supports HDR formats Including HDR, HDR10, HDR10+, Dolby Vision, HLG, BBC and NHK. All of them are supported in up to 4K 60Hz and up to 12 Bit Deep Color. All color space compression is compatible. This powerhouse matrix switcher is the ideal solution for a multi zone setups that need audio downmixing. Control is not a problem, through the web GUI you can manage all the settings and controls. We also offer drivers for all the top control systems. Combine that with the LED setup screen on the front and management is a breeze. The AC-MX1616-AUHD-HDBT-AVDM will become a staple in your large demanding installations!

AC-MX1616-AUHD

The AC-MX1616-AUHD is a true high bandwidth powerhouse. Supporting the full HDMI 2.0a/b specification and supporting every flavor of HDR, this matrix will ensure you can get the most out of any system. This unit supports uncompressed HDR formats Including HDR, HDR10, HDR10+, Dolby Vision, HLG, BBC and NHK. All of them are supported in up to 4K 60Hz and up to 12 Bit Deep Color. All color space compression is compatible. Our unique design has allowed us to improve high bandwidth switching speeds. Average speeds of less than 3 seconds – this is an industry best for this advanced level of actual uncompressed, high bandwidth w/ HDR switching. Maximum compatibility and speed improve the customer experience immensely. The sleek, low-profile and high-density design make for a sleek machine that saves you valuable space in the rack room. This combined with a OLED setup screen on the front that makes setup and management a breeze will make this a staple in your large demanding installations!

8x8 Matrix Switchers

AC-MX88-AUHD-HDBT-PLUS

The AC-MX88-AUHD-HDBT-PLUS is a true 8×8 HDMI/HDBaseT matrix switch. This unit includes 8 HDMI inputs, and 8 HDMI/HDBaseT output blocks. These output blocks include a HDBaseT and HDMI port, these ports are mirrored, and both are active. This Matrix supports HDMI 2.0(a/b), HDCP 2.2, up to 4K video resolution, and up to 18 Gbps bandwidth. We are able to pass 18Gbps through category cable by using the new HDBaseT technology we have developed called “ICT”, learn more about ICT below. This switch allows any source (Blu-ray, UHD Blu-ray, satellite receiver, game consoles, PCs, etc … ) to be shown on any of the connected displays. This matrix equalizes and amplifies the output to ensure the HDMI signal can be transmitted through long HDMI cables without loss of quality. Audio Delay is “On-Board” so you can manage lip-sync issue before it is a problem. Also with built in Scalers you don’t have to forfeit that 4K signal just because you have a couple older displays. All that with Full EDID management allows maximum flexibility with today’s wide mixture of sources and displays. This is an ideal solution for digital entertainment centers, HDTV retail, show sites, data centers, schools, conference and training centers and more!

AC-MX88-AUHD-HDBT-AVDM

The AC-MX88-AUHD-HDBT-AVDM is a high bandwidth audio/video matrix switcher. What really makes this product special is the ability to downmix bitstream audio beyond 7.1 channel into a 2 channel audio signal via all 8 inputs, that includes Dolby Atmos and DTS-X. In a multi zoned distribution system every zone is not set to handle full dolby atmos sound. Most zones are going to need 2 channel audio. This AC-MX88-AUHD-HDBT-AVDM Matrix Switcher allows you to deliver 24+ channels to your Dolby Atmos home theater, at the same time it delivers 2 channel to the rest of the zones. We do this by allowing the downmixing to only affecting the de-embedded audio outputs, the HDBaseT and HDMI ports leave the audio unimpeded, allowing you to distribute full dolby Atmos and DTS HD through them. Supporting the full HDMI 2.0 a/b specification and supporting every flavor of HDR, this matrix will ensure you can get the most out of any system. This 8×8 downming matrix supports HDR formats Including HDR, HDR10, HDR10+, Dolby Vision, HLG, BBC and NHK. All of them are supported in up to 4K 60Hz and up to 12 Bit Deep Color. All color space compression is compatible. This powerhouse matrix switcher is the ideal solution for a multi zone setups that need audio downmixing. Control is not a problem, through the web GUI you can manage all the settings and controls. We also offer drivers for all the top control systems. Combine that with the LED setup screen on the front and management is a breeze. The AC-MX88-AUHD-HDBT-AVDM will become a staple in your large demanding installations!

AC-MX88-AUHD-GEN2

The AC-MX88-AUHD is a true 8×8 HDMI matrix switch. Supporting HDMI 2.0(a/b), HDCP 2.2, up to 4K video resolution, and up to 18 Gbps bandwidth. This switch allows any source (Blu-ray, UHD Blu-ray, satellite receiver, game consoles, PCs, etc … ) to be shown on any of the connected displays. This matrix equalizes and amplifies the output to ensure the HDMI signal can be transmitted through long HDMI cables without loss of quality. Audio Delay is “On-Board” so you can manage lip-sync issue before it is a problem. Also with built in Scalers you don’t have to forfeit that 4K signal just because you have a couple older displays. All that with Full EDID management allows maximum flexibility with today’s wide mixture of sources and displays. This is an ideal solution for digital entertainment centers, HDTV retail, show sites, data centers, schools, conference and training centers and more!

AC-MX88-AUHD-NSFS

The AC-MX88-AUHD-NSFS is a true 18Gbps 4K60 (4:4:4) 8×8 HDMI matrix switch. Supporting HDMI 2.0(a/b), HDCP 2.2, up to 4K video resolution, and up to 18 Gbps bandwidth. This switch allows any source (Blu-ray, UHD Blu-ray, satellite receiver, game consoles, PCs, etc … ) to be shown on any of the connected displays. This matrix equalizes and amplifies the output to ensure the HDMI signal can be transmitted through long HDMI cables without loss of quality. This matrix was built with switching speed in mind. With the introduction of high bandwidth 4K, switching times increase because of all the added data compared to legacy resolutions like 720p or 1080i/p. In this unit we have removed scaling control and audio delay control in order to give the integrator the fastest possible switching time in a 18Gbps switch. Welcome to the NSFS. This is an ideal solution for digital entertainment centers, HDTV retail, show sites, data centers, schools, conference and training centers and more!

4x4 Matrix Switchers

AC-MX44-AUHD-HDBT

The AC-MX44-AUHD-HDBT is a true 4×4 HDMI/HDBaseT matrix switch. This unit includes 4 HDMI inputs, and 4 HDMI/HDBaseT output blocks. These output blocks include a HDBaseT and HDMI port, these ports are mirrored, and both are active. This Matrix supports HDMI 2.0(a/b), HDCP 2.2, up to 4K video resolution, and up to 18 Gbps bandwidth. We are able to pass 18Gbps through category cable by using the new HDBaseT technology we have developed called “ICT”, learn more about ICT below. This switch allows any source (Blu-ray, UHD Blu-ray, satellite receiver, game consoles, PCs, etc … ) to be shown on any of the connected displays. This matrix equalizes and amplifies the output to ensure the HDMI signal can be transmitted through long HDMI cables without loss of quality. Audio Delay is “On-Board” so you can manage lip-sync issue before it is a problem. Also with built in Scalers you don’t have to forfeit that 4K signal just because you have a couple older displays. All that with Full EDID management allows maximum flexibility with today’s wide mixture of sources and displays.

AC-MX44-AUHD

The AC-MX44-AUHD is a true 4×4 HDMI matrix switch. Supporting HDMI 2.0(a/b), HDCP 2.2, up to 4K video resolution, and up to 18Gbps bandwidth. This switch allows any source (Blu-ray, UHD Blu-ray, satellite receiver, game consoles, PCs, etc) to be shown on any of the connected displays. This matrix equalizes and amplifies the output to ensure the HDMI signal can be transmitted through long HDMI cables without loss of quality. Audio Delay is “On-Board” so you can manage lip-sync issue before it is a problem. Also with built in Scalers you don’t have to forfeit that 4K signal just because you have a couple older displays. All that with Full EDID management allows maximum flexibility with today’s wide mixture of sources and displays.
