Media Converters

Upgrade & extend devices with TechLogix media converters. TechLogix media converters adapt fiber signals to a variety of different formats and cable types. Media converters integrate twisted pair electronics with fiber optic cable to extend transmission distance and create immunity from surges, static, lightning and interference. Media converters also adapt single mode fiber to multimode
fiber and vice versa.

What do they do?

Integrate twisted pair devices with fiber optic cable
Extend signal distances up to 550m (1,805 feet) using multimode fiber
Extend signal distances up to 20km (12.4 miles) using single mode fiber
Create immunity from lightning, static electricity, surges, electromagnetic interference and RF interference
Compatible with network-based devices, such as cameras, network switches, routers, access points, computers and servers

Product Options

TL-MC-1S1R

One RJ45 to one SFP (fiber)

The TL-MC-1S1R features one SFP port (SFP module sold separately) and one RJ45 twisted pair port, effectively adapting twisted pair-based devices to fibre for longer transmission distances. The MC-1S1R supports multimode fibre when paired with a multimode SFP module and single mode fibre when paired with a single mode SFP module.

Convert signals from twisted pair to fiber and vice versa | One SFP (fiber) port and one RJ45 (twisted pair) port | 10/100/1000M data rate | 850nm/1310nm/1550nm supported wavelengths | Single mode and multimode fiber compatible (SFP module dependent) | SFP module sold separately | Suggested multimode module: TL-1GSFP-MM550 | Multimode max distance: 550m (1,805 ft.) | Suggested single mode module: TL-1GSFP-SM20K | Single mode max distance: 20km (12.4 miles) | 0 degree to 60 degree C operating temperature | 1.0″ x 2.75″ x 3.6″ (26mm x 70mm x 93mm) | 5V power supply (included) | IEEE 802.3z & 802.3ab compliant | MDI/MDIX auto-crossover | Jumbo frame (64-9216 byte) | Voltage monitor support | Diagnostic LEDs | Plug-and-play compliant

TL-MC-1S2R

Two RJ45s to one SFP (fiber)

The TL-MC-1S2R features one SFP port (SFP module sold separately) and two RJ45 twisted pair ports, effectively adapting twisted pair-based devices to fibre for longer transmission distances. The MC-1S2R supports multimode fibre when paired with a multimode SFP module and single-mode fibre when paired with a single mode SFP module.

Convert signals from twisted pair to fiber and vice versa | One SFP (fiber) port and two RJ45 (twisted pair) ports | 10/100/1000M data rate | 850nm/1310nm/1550nm supported wavelengths | Single mode and multimode fiber compatible (SFP module dependent) | SFP module sold separately | Suggested multimode module: TL-1GSFP-MM550 | Multimode max distance: 550m (1,805 ft.) | Suggested single mode module: TL-1GSFP-SM20K | Single mode max distance: 20km (12.4 miles) | 0 degree to 60 degree C operating temperature | 1.0″ x 2.75″ x 3.6″ (26mm x 70mm x 93mm) | 5V power supply (included) | IEEE 802.3z & 802.3ab compliant | MDI/MDIX auto-crossover | Jumbo frame (64-9216 byte) | Voltage monitor support | Diagnostic LEDs | Plug-and-play compliant

TL-MC-1S1S

One SFP (fiber) to one SFP (fiber)

The TL-MC-1S1S features two SFP ports (SFP module sold separately), effectively adapting signals between different fibre types. In most applications, the TL-MC-1S1S adapts single-mode fibre to multimode fibre and vice versa. The MC-1S1S supports multimode fibre when paired with a multimode SFP module and single mode fibre when paired with a single mode SFP module

Convert signals between different fiber types (single mode to multimode and vice versa) | Two SFP (fiber) ports | 100Mbps to 1250Mbps data rates | 850nm/1310nm/1490nm/1550nm supported wavelengths | Single mode and multimode fiber compatible (SFP module dependent) | SFP module sold separately | Suggested multimode module: TL-1GSFP-MM550 | Multimode max distance: 550m (1,805 ft.) | Suggested single mode module: TL-1GSFP-SM20K | Single mode max distance: 20km (12.4 miles) | 0 degree to 60 degree C operating temperature | 1.0″ x 2.75″ x 3.6″ (26mm x 70mm x 93mm) | 5V power supply (included) | IEEE 802.3z & 802.3ab compliant | 1000Base – SX/LX/EX/ZX | Diagnostic LEDs | Plug-and-play compliant
